pst-circ – PSTricks package for drawing electric circuits

The pack­age is built us­ing PSTricks and in par­tic­u­lar pst-node. It can eas­ily draw cur­rent 2-ter­mi­nal de­vices and some 3- and 4-ter­mi­nal de­vices used in elec­tronic or elec­tric the­ory. The pack­age’s macros are de­signed with a view to ‘log­i­cal’ rep­re­sen­ta­tion of cir­cuits, as far as pos­si­ble, so as to re­lieve the user of purely graph­i­cal con­sid­er­a­tions when ex­press­ing a cir­cuit.

Sources /graphics/pstricks/contrib/pst-circ
Ver­sion 2.15 2017-11-16
Li­cense The Project Public Li­cense
Main­tainer Her­bert Voß
Christophe Jorssen (in­ac­tive)
Con­tained in TeX Live as pst-circ
MiKTeX as pst-circ
Topics cir­cuit di­a­grams
pack­age us­ing PStricks for graph­i­cal out­put

Down­load the con­tents of this pack­age in one zip archive (556.1k).
