grafcet – Draw Grafcet/SFC with TikZ

The package provides a library (GRAFCET) that can draw Grafcet Sequential Function Chart (SFC) diagrams, in accordance with EN 60848, using Pgf/TikZ.

Sources/graphics/pgf/contrib/grafcet
Documentation
Home pagehttp://sciences-indus-cpge.papanicola.info/Grafcet-avec-pgf-Tikz
Version1.3.5
LicensesThe Project Public License 1
MaintainerRobert Papanicola
Contained inTeX Live as grafcet
MiKTeX as grafcet
TopicsPGF TikZ
Diagrams
See alsotikz-sfc

Download the contents of this package in one zip archive (304.8k).
